AVK GATE VALVE FLANGED, CL 300
Face/Face ASME B16,10, OS&Y, Rising stem, Flexible wedge, Bolted bonnet, Welded seat ring
AVK Flanged gate valve ASME/B16. For the use of water, liquids, gas and steam within industrial branches and in various projects.
AVK industrial gate valves are tailor made with straight, angle versions, and built-in non-return version. They can shut off very high pressures while they are also suitable for regulating flow. They can be offered in cast iron, steel, bronze and stainless steel as well as in special materials for high temperatures and aggressive media. It features an outstanding durability. Temperature ranges between -196°C to 649°C
| Variant 1485/10-004 | |
|---|---|
| DN: | DN50 - DN200 |
Features
- Full certified products, they are designed in accordance with key international standards
- Tailor made valves with top quality
- Destructive and non-destructive testing of materials according to relevant standards and specified customer requirements
- Larger size availability
- Cost-effective
- Pressure testing according to API 589/API 6D
Downloads
Datasheet
Certificate(s)
Reference nos. and dimensions:
Scroll for more info
| AVK ref. no. | DN mm |
H open mm |
L mm |
W mm |
Theoretical weight/kg |
|---|---|---|---|---|---|
| 1485-0050-10-0000014 | 50 | 430 | 216 | 200 | 23 |
| 1485-0065-10-0000007 | 65 | 453 | 216 | 200 | 35 |
| 1485-0080-10-0000007 | 80 | 475 | 282 | 250 | 48 |
| 1485-0100-10-0000008 | 100 | 579 | 305 | 280 | 70 |
| 1485-0150-10-0000015 | 150 | 782 | 403 | 355 | 130 |
| 1485-0200-10-0000009 | 200 | 1026 | 419 | 450 | 209 |
Enquiry
Scroll for more info
Components
| 1. | Body | ASTM A351 CF8M EN 1.4408 |
| 2. | Bonnet | ASTM A351 CF8M EN 1.4408 |
| 3. | Bonnet bolt | ASTM A193-B8 |
| 4. | Nut | ASTM A194-8 |
| 5. | Eye bolt | ASTM A193-B8 |
| 6. | Nut | ASTM A194-8 |
| 7. | Washer | Stainless steel AISI 316 |
| 8. | Pin | Stainless steel AISI 316 |
| 9. | Handwheel | Ductile Iron |
| 10. | Nut | Steel |
| 11. | Stem nut | Brass |
| 12. | Nut | Steel |
| 13. | Washer | Steel |
| 14. | Oil cup | Copper |
| 15. | Gland flange | ASTM A351 CF8M EN 1.4408 |
| 16. | Gland | ASTM A351 CF8M EN 1.4408 |
| 17. | Packing | Graphite |
| 18. | Backseat bushing | ASTM A351 CF8M EN 1.4408 |
| 19. | Stem | ASTM A182 F316 |
| 20. | Gasket | SS 316 (1.4401) and graphite |
| 21. | Disc | ASTM A351 CF8M EN 1.4408+STL |
| 22. | Seat | ASTM A351 CF8M EN 1.4408+STL |
Test/Approvals
- Produced according to API-6D certificate 6D-1745
- Management system standards approved according to ISO 9001:2015
- PED 2014/68/EU approved according to certificate DGR-0036-QS-1125-22
