Gunric Butterfly Valve, Triple Eccentric
PN40, metal seated, WCB body
Contact
Mark Wilson
Product Manager - Engineering
EN593, WCB disc, raised face (DWS) flanges EN 1092, SS 304 seat ring, lam. SS 316 seal, SS 431 shaft, steel/PTFE bush, 300-400µm 2-pack Carboline EP coating, DN100-1500
| Variant 6145/11-001 | |
|---|---|
| DN: | DN250 - DN1200 |
| PN: | PN 40 |
Features
- Gases and liquids: Air; Water; Steam; Oil; Chemicals; Various acids; CO2; CO3; CO; SO2; SO3.
- Operating temperatures from cryogenic to +1 000°Celcius
- High pressure operation – up to CL 1 500
- Actuation with manual gearboxes, pneumatic / electric / hydraulic actuators
- Small, medium and large diameter pipelines
- Metal seated with a solid disc
- Face to face dimensions
- Cast stell or S6 iron
- Seal constructed from laminated stainless stell or solid metal
- Right hand closing or Left hand closing options avalable
Downloads
Datasheet
Reference nos. and dimensions:
Scroll for more info
| AVK ref. no. | DN mm |
Flange drilling |
|---|---|---|
| 6145-0250-11-0935200000 | 250 | PN40 |
| 6145-0400-11-0935200000 | 400 | PN40 |
| 6145-0500-11-0935200000 | 500 | PN40 |
| 6145-0700-11-0935200000 | 700 | PN40 |
| 6145-0800-11-09352AI000 | 800 | PN40 |
| 6145-1000-11-09352AL000 | 1000 | PN40 |
| 6145-1200-11-09352AL000 | 1200 | PN40 |
